(DEMO PRODUCT) RESEPI-TELEDYNE CL-360HD by Inertial Labs
ARRAY GeoSpatial
(DEMO PRODUCT) RESEPI-TELEDYNE CL-360HD by Inertial Labs
The RESEPI CL-360HD by Inertial Labs was strategically designed for projects requiring high performance. Due to its powerful 4-return laser and increased range of up to 750m, the CL-360HD would be perfect for mobile mapping, forestry, and crack detection in critical infrastructure areas like airport runways. Because of this diverse use-case portfolio and its 360 FOV, the RESEPI can be used for many services, including utility mapping (power lines), construction volumetrics, site surveying, precision agriculture, forestry, mining operations, and others.
RESEPI Overview
RESEPI™ (Remote Sensing Payload Instrument) is a sensor-fusion platform designed for accuracy-focused remote sensing applications. RESEPI utilizes a high-performance Inertial Labs INS (GPS-Aided Inertial Navigation System) with a tactical-grade IMU and a high-accuracy single or dual-antenna GNSS receiver, integrated with a Linux-based processing core and data-logging software. The platform also provides a WiFi interface, optional imaging module, and external cellular modem for RTCM corrections. RESEPI can be operated by a single hardware button or from a wirelessly connected device via a simple web interface.
RESEPI WITH TELEDYNE CL-360HD
RESEPI equipped with TELEDYNE’s CL-360HD LiDAR is Inertial Labs’ entrance solution to the precision solution market. This powerful system will meet users’ needs, needing the best return count, range, beam divergence, accuracy, and precision. It offers a range of different laser scan speeds and frequencies, allowing users to tweak the settings to match the desired use case easily.
Key System Features of RESEPI™ TELEDYNE CL-360HD Drone LiDAR Scanner
- System Vertical Accuracy: 1 – 2 cm(1)
- Precision: 1 – 2 cm(2)
- Precision: (1σ Noise Removal) 1 – 2 cm (3)
- Recommended AGL: Up to 200 m
- Weight: 4.3 kg (without camera)
- Dimensions: 36.9 x 16 x 15.5 (cm)
- Max Flight Time (DJI M600): 23 minutes (TB48S batteries)
- External Storage: 256GB USB Included
- System Computer: Quad Core, 1GB RAM,8GB eMMC
- Operational Voltage Range: 9-436V
- Power Consumption:42W (@ 100 Hz); 47W (@ 250 Hz)
LiDAR
Laser Range Capabilities(100kHz)
205m @ 10% ref.;
290m @ 20% ref.;
490m @ 50% ref.;
1.5 to 750m(4)
Laser Range Capabilities(200kHz)
130m @ 10% ref.;
185m @ 20% ref.;
250m @ 50% ref.;
1.5 to 750m(5)
Range Accuracy
+/- 5 mm
FOV (Horizontal)
360°
FOV (Vertical)
NA
Scan Angle (Vertical)
NA
Laser Beam Divergence
0.017°(6)
Number of Laser
1
Number of Returns
4
Scan Speed
50-250 lines/sec
IMU
Inertial Labs Tactica
Grade IMU-P
Grade IMU-P
GNSS
Dual Antenna
Constellations
GPS, GLONASS, Galileo, BeiDou,
QZSS, NavIC (IRNSS), SBAS, L-Band(7)
QZSS, NavIC (IRNSS), SBAS, L-Band(7)
Frequencies
L1, L2, L5(8)
Operation Modes
RTK and PPK
Output Rates
Up to 200Hz (INS);
Up to 2,000Hz (IMU)
Up to 2,000Hz (IMU)
Pitch/Roll Accuracy
0.03° (RTK);
0.006° (PPK)(9)
0.006° (PPK)(9)
Heading Accuracy
0.15° (RTK);
0.03° (PPK)(10)
0.03° (PPK)(10)
Velocity Accuracy
<0.03 m/s
Position Accuracy
1cm + 1ppm (RTK);
0.5cm (PPK)
0.5cm (PPK)
Software
Field Checks
Yes, Included
Pre-Processing
Yes, Included
Post-Processing
Yes, Supported
